Golden Designs "St. Moritz" 2 Person Barrel Traditional Sauna (GDI-B002-01)

Description

The barrel sauna format has a physics advantage that flat-wall box saunas do not: the curved interior eliminates dead air in the corners, concentrates the heat toward the seating area, and allows a significantly smaller cubic volume to reach temperature faster than a rectangular room of the same footprint. Golden Designs built the St. Moritz around that principle. At 2-person capacity with a 60-inch depth and a 75-inch-wide barrel, the St. Moritz reaches its ideal operating range of 170 to 185 degrees Fahrenheit in less time and with less energy than comparably sized box saunas -- and it holds that heat with the kind of consistency that makes the difference between a session that works and one that just gets warm. This is the version of the barrel sauna that is built to perform from the day it goes up, not just to look the part.



The barrel is constructed from Pacific Premium Cedar -- a wood chosen for outdoor sauna applications because of its natural oil content, its resistance to moisture and insects, and the aromatic quality that fills the interior when the stove fires up. Pacific cedar has a tighter, denser grain than Eastern White Cedar, giving it greater natural weather resistance and a longer outdoor service life with minimal maintenance. The exterior stave construction holds the barrel shape under the stainless steel bands that cinch the sauna together, and the structure is designed to expand and contract with temperature and humidity changes without compromising the integrity of the seal. The bronze privacy tempered glass door and matching stainless steel hinges and handle add durability and a clean, finished appearance to the front face of the barrel.



Inside, the St. Moritz is a purpose-built sauna room, not a converted outdoor box. The interior backrests on both sides of the bench include integrated accent lighting, creating a warm, low-level glow that makes the session feel deliberate rather than utilitarian. The LED control panel allows lighting adjustment without reaching for the stove. The two-tier bench configuration runs along both sides of the interior, giving two adults genuine room to sit or recline. The stove is a 6kW unit with built-in controls, wall-mounted and positioned at the front interior per the installation instructions. The 6kW output is appropriate for the St. Moritz's interior volume, and an 8kW upgrade is available for buyers who want faster heat-up or who plan to use the sauna in colder climates.



The sauna arrives in three crates and assembles with standard hand tools -- a battery-powered Phillips screwdriver, claw hammer, and 17mm wrench. Three adults are recommended for assembly, primarily for the steps that require holding the front and rear wall panels while the staves are set. The sauna is designed for outdoor placement and can be positioned on a concrete slab, concrete pavers, gravel, cinder blocks, or a solid wood deck. The stainless steel bands will need periodic tightening every four to six months as the cedar expands and contracts with seasonal changes -- a standard maintenance step for all stave-construction barrel saunas.



The St. Moritz carries a 5-year limited warranty on electronics and a 1-year warranty on the stove from the original date of purchase. The sauna is suitable for residential and light commercial use. Warranty registration is required within 60 days of purchase.



Backyard Prime Living is a certified authorized reseller of Golden Designs. Every purchase includes full manufacturer warranty support and our commitment to extraordinary customer care.



Features

• Pacific Premium Cedar Barrel Construction -- The St. Moritz is built from Pacific Premium Cedar staves throughout, chosen for its natural oil content, moisture and insect resistance, and the aromatic quality it delivers at sauna temperatures. Pacific cedar is denser and more weather-resistant than lighter cedar species, making it the right material for a permanent outdoor barrel installation.
• Barrel Design for Fast, Efficient Heating -- The curved stave barrel format eliminates dead air volume in the corners, concentrates heat at the seating zone, and allows the interior to reach operating temperature faster than a flat-wall room of comparable footprint. The result is shorter heat-up times and more consistent session temperatures.
• 2-Person Capacity -- The St. Moritz is sized for two adults with room to sit comfortably or recline on the bench. The compact footprint -- 75 inches wide and 60 inches deep -- makes it the right choice for residential and light commercial installations where space and privacy matter more than group capacity.
• 6kW Stove with Built-In Controls -- The St. Moritz ships with a 6kW electric sauna stove, wall-mounted inside the front of the barrel with built-in temperature controls. Ideal operating temperature is 170 to 185 degrees Fahrenheit; maximum is 190 degrees.
• Optional 8kW Stove Upgrade Available -- An 8kW stove upgrade is available at time of order for buyers who want faster heat-up times or who plan to operate the sauna in colder ambient temperatures. The 8kW configuration requires a 240V / 40AMP circuit.
• Bronze Privacy Tempered Glass Door -- The sauna door is bronze privacy tempered glass, providing an aesthetically consistent finish to the front wall panel while maintaining the heat seal and giving privacy from outside the barrel.
• Stainless Steel Hinge and Handle -- All exterior hardware is stainless steel, including the door hinge and handle. Stainless construction resists corrosion and weather exposure and ensures the hardware outlasts the sauna structure itself.
• Interior Backrest with Accent Lighting -- Backrests on both sides of the interior bench include integrated accent lighting, creating a warm ambient glow inside the barrel during sessions. No overhead glare -- just low, directional light that adds to the experience without distracting from it.
• Interior LED Control Panel for Accent Lighting -- The LED lighting is adjustable via an interior control panel, allowing the user to set the mood for each session without leaving the bench.
• Sandglass Timer and Full Accessory Set Included -- The St. Moritz includes a sandglass (sauna sand timer), wooden bucket, and scoop. Everything needed to run a traditional sauna session arrives in the box.
• Two-Tier Bench Configuration -- Interior bench seating runs along both sides of the barrel on two tiers, giving two adults the option to sit at different heat levels or recline fully during a session.
• Stave Construction with Stainless Steel Bands -- The barrel is assembled from individual cedar staves tensioned by stainless steel bands. The bands must be checked and tightened every four to six months as the cedar expands and contracts with seasonal changes -- a standard maintenance step specific to stave-construction saunas.
• Outdoor Rated -- The St. Moritz is designed for outdoor placement. Pacific cedar naturally resists weathering, and an exterior wood water repellent treatment is recommended within one month of assembly and two to three times per year thereafter. Surface color will change naturally over time with UV and weather exposure.
• Rain Cover Included -- A rain cover is included for times when the sauna is not in use, providing a weather barrier over the top of the barrel between sessions.
• Ships in 3 Crates -- The sauna ships in three crates via freight carrier (curbside delivery). Three adults are recommended for assembly.
• Residential and Light Commercial Use -- The St. Moritz is rated for both residential and light commercial applications.
• 120V / 15AMP Circuit for Interior Lighting -- A separate 120V / 15AMP circuit is required to power the interior accent lighting control panel, independent of the stove circuit.
• 5-Year Warranty on Electronics / 1-Year Warranty on Stove -- Golden Designs warrants the electronics for 5 years and the stove for 1 year from the original date of purchase. Warranty registration required within 60 days of purchase.



What's Included

ALL GDI-B002-01 CONFIGURATIONS INCLUDE:

• Pacific Premium Cedar barrel sauna structural kit -- all staves, front wall panel, rear wall panel, and support cradles
• Stainless steel bands for barrel assembly
• 6kW traditional sauna stove with built-in controls and stove stones (shipped in separate crate)
• Stove guard (assembled wood frame for heater protection)
• Two-tier cedar bench system (bench panels, bench support wood, bench back wood planks, bench front wood planks)
• Interior backrests with integrated accent lighting (both sides)
• Interior LED control panel for accent lighting - Bronze privacy tempered glass door with stainless steel hinge and handle
• Rain cover (optional installation -- included in crate)
• Sandglass (sauna sand timer)
• Wooden bucket and scoop
• All assembly hardware (stainless steel screws, nails, bands, leveler, rubber mallet, hex screwdriver)
• Owner's manual

OPTIONAL UPGRADE (AT TIME OF ORDER): - 8kW stove upgrade (replaces standard 6kW stove; requires 240V / 40AMP circuit)

NOT INCLUDED / SOLD SEPARATELY:

• Thermometer (not listed in standard kit -- verify with Golden Designs)
• Sauna foundation or base (concrete pad, pavers, gravel, cinder blocks, or solid wood deck -- customer responsibility)
• Electrical wiring and circuit installation: 240V / 30AMP for 6kW stove OR 240V / 40AMP for 8kW stove upgrade, PLUS separate 120V / 15AMP for interior lighting controls -- all electrical connections must be made by a certified electrician
• Exterior wood water repellent treatment (recommended within 1 month of assembly and 2-3 times per year; not included)
• Additional accessories (drink shelf, magazine rack, robe hook -- available separately)

INSTALLATION NOTE: The sauna must be placed on a level surface capable of supporting the assembled weight of the sauna plus occupants, which can exceed 1,000 lbs. Approved base types include concrete slab, concrete pavers, gravel, cinder blocks, and solid wood deck. Do not move the sauna after assembly. All electrical connections must be made by a certified electrician using copper wire with a 90-degree Celsius rating. Aluminum wiring cannot be used. Stainless steel bands must be inspected and tightened every 4 to 6 months. Apply exterior wood water repellent treatment within one month of assembly and 2 to 3 times per year to protect the cedar from UV and weather exposure.



Specifications

Manufacturer: Golden Designs Inc.
Model Name: "St. Moritz" 2 Person Barrel Traditional Sauna
Model Number: GDI-B002-01
Collection: Barrel Traditional Outdoor Sauna Series
Product Type: Outdoor barrel sauna -- traditional steam / electric stove
Wood Species: Pacific Premium Cedar (no stain)
Use: Residential / Light Commercial

EXTERIOR DIMENSIONS (ASSEMBLED):
Overall Width: 75 in
Overall Depth: 60 in
Overall Height: 80 in

WEIGHT:
Assembled Weight: 409 lbs
Shipping Weight (main crate, without stove and stones): 515 lbs
Shipping Weight (stove crate): 35 lbs
Shipping Weight (stones crate): 45 lbs
Total Shipping Weight (with stove and stones): 595 lbs

SHIPPING:
Ships in: 3 crates
Main Crate Dimensions: 44 in W x 74 in D x 25 in H (add 13 in to top of crate for height with lid)
Stove Crate Dimensions: 13 in W x 20 in D x 28 in H
Stones Crate Dimensions: 11 in W x 16 in D x 6 in H
LTL Pallet Dimensions: 74 in W x 45 in D x 38 in H / LTL Pallet Weight: 595 lbs
Delivery Method: LTL freight, curbside standard
Ships From: Ontario, CA (ZIP 91761)
Processing Time: 1 business day

CONSTRUCTION:
Material: Pacific Premium Cedar (stave barrel construction, no stain)
Exterior Hardware: Stainless steel (bands, hinges, handle, screws)
Door: Bronze privacy tempered glass with stainless steel hinge and handle
Rain Cover: Included (optional installation)
Support Cradles: 3 cradles (standard for 2-person model)

HEATING:
Stove: 6kW electric traditional sauna stove with built-in controls
Stove Stones: Included
Ideal Temperature Range: 170 to 185 degrees Fahrenheit
Maximum Temperature: 190 degrees Fahrenheit
Optional Upgrade: 8kW stove (available at time of order)

ELECTRICAL:
Standard (6kW stove): 240V / 30AMP dedicated circuit (hardwired)
Upgrade (8kW stove): 240V / 40AMP dedicated circuit (hardwired)
Interior Lighting Controls: 120V / 15AMP dedicated circuit
Wire Requirement: Copper wire, 90-degree Celsius rating minimum; aluminum wiring not permitted
Electrician Required: Yes -- all connections must be made by a certified licensed electrician

CAPACITY: 2 people

BASE REQUIREMENTS:
Approved base types: Concrete slab, concrete pavers, gravel, cinder blocks, solid wood deck
Surface must be level and capable of supporting assembled weight plus occupants (can exceed 1,000 lbs)
Base not included

MAINTENANCE:
Stainless steel band inspection and tightening: Every 4 to 6 months
Exterior wood water repellent treatment: Within 1 month of assembly; repeat 2 to 3 times per year
Interior cleaning: Non-toxic, water-based cleaner only; no chemical-based cleaners or detergents

WARRANTY:
Electronics (control panel, harnesses, lighting): 5 years from original date of purchase
Stove: 1 year from original date of purchase
Warranty Registration Required: Within 60 days of purchase date
Warranty Registration: https://app.goldendesigninc.com/public/RegisteredProduct
